YSO(Ce) Scintillation Crystal
YSO(Ce), or cerium-doped yttrium orthosilicate, is a non-hygroscopic scintillation crystal used in X-ray and gamma detection, charged-particle measurement, nuclear physics experiments, and detector research. Because it contains no lutetium, YSO(Ce) does not have the Lu-176 intrinsic activity associated with LYSO(Ce), although total detector background still depends on material purity, packaging, photosensor, electronics, and the operating environment. Typical reference values include a density of about 4.45 g/cm3, an emission peak near 420 nm, and a decay time of approximately 50-70 ns. ATR Crystal supplies custom YSO(Ce) crystals, screens, and array components with dimensions, surface finish, reflector, and readout requirements reviewed according to the detector design.
Built around your specification
- Chemical formula
- Y2SiO5:Ce
- Material type
- Cerium-doped yttrium orthosilicate
- Hygroscopicity
- none
- Intrinsic background
- No Lu-176 background
Final specifications and acceptance criteria are confirmed for the quoted configuration.
Request a quotationOverview
YSO(Ce) Lutetium-Free Scintillation Crystal
YSO(Ce) scintillation crystal, also written as YSO:Ce, is cerium-doped yttrium orthosilicate (Y2SiO5:Ce). This non-hygroscopic, lutetium-free material is considered for radiation detection, imaging research and low-background detector studies.
ATR Crystal supplies YSO(Ce) Scintillation Crystal for research, industrial, medical, security, and OEM projects. Dimensions, surface finish, packaging, readout matching, and inspection requirements can be reviewed according to your drawing or application.
Because the YSO host contains no lutetium, it avoids the Lu-176 contribution associated with lutetium-based scintillators. This does not mean that a finished detector has zero background. Material purity, surrounding components, photosensor, electronics and environment still need review for the intended measurement.
Explore the scintillation crystal range and scintillator selection guide when comparing material and readout requirements.
Advantages of YSO(Ce) Scintillation Crystal
- Lutetium-free compositionYSO(Ce) avoids Lu-176 intrinsic background found in lutetium-containing scintillators.
- Non-hygroscopic materialThe crystal is easier to handle than hygroscopic scintillators.
- Useful emission for photosensorsYSO(Ce) can be matched to common scintillation readout systems.
- Custom geometryCrystals can be fabricated to requested dimensions.
- Alternative silicate scintillatorYSO(Ce) can be considered where LYSO background is undesirable.
- Research detector useSuitable for detector development and comparative scintillator studies.
Customization and Quality Control
- Drawing reviewDimensions, tolerances, surface finish, and assembly details are reviewed before quotation.
- Material and geometry checkThe selected material and product geometry are checked against the intended application.
- Optical and visual inspectionSurface quality, chips, scratches, coating, and appearance can be inspected according to project requirements.
- Performance-related testingScintillation response and optical inspection can be reviewed when test conditions and acceptance criteria are defined.
- Packaging supportProtective packaging, wrapping, housing, or handling requirements can be specified for shipment and integration.
- Prototype to batch supplySmall samples and repeat production can be supported depending on material availability and specification.
Specifications
YSO(Ce) Scintillation Crystal Specifications
Key Specifications and Options
| Parameter | Typical Value / Option |
|---|---|
| Chemical formula | Y2SiO5:Ce |
| Material type | Cerium-doped yttrium orthosilicate |
| Hygroscopicity | Non-hygroscopic |
| Intrinsic background | No Lu-176 background |
| Format | Custom polished scintillation crystals |
YSO(Ce) vs. LYSO(Ce) and GAGG(Ce)
Compare host composition, component geometry, optical readout and the required measurement background. The following review points support material selection; they do not specify guaranteed detector performance.
| Material | Selection distinction | Review for the project |
|---|---|---|
| YSO(Ce) | Lutetium-free silicate scintillator without the Lu-176 contribution of a lutetium-based host. | Required radiation range, thickness, light collection and measured background. |
| LYSO(Ce) | Lutetium-containing silicate used for compact gamma detection and PET research. | Intrinsic Lu-176 background, geometry and photosensor response in the intended energy window. |
| GAGG(Ce) | Lutetium-free, green-emitting garnet scintillator. | Emission/readout matching, material grade, afterglow conditions and required format. |
A published study of intrinsic radioactivity in LYSO describes the Lu-176 contribution. For low-count-rate work, provide the energy window, acquisition conditions and background acceptance criteria.
YSO(Ce) Physical and Scintillation Properties
The following existing YSO(Ce) material values are reference data. Confirm the crystal grade, dimensions, readout and measurement conditions when defining acceptance tests.
| Properties of YSO(Ce) Scintillators (YSO:Ce Scintillators) | |
| Density (g/cm3) | 4.45 |
| Decay Constant (ns) | 50-70 |
| Wavelength of Emission Max (nm) | 420 |
| Relative Light Output of NaI(Tl) | 70% |
| Melting Point (K) | 2000 |
| Refractive Index of Emission Max | 1.8 |
| Hygroscopicity | none |
| Cleavage | none |
The decay-time range and light output are material reference values. They do not specify a finished detector’s timing, detection efficiency or background. Confirm the excitation, temperature, photosensor response and integration conditions when comparing light output relative to NaI(Tl).
Applications
Applications of YSO(Ce) Scintillation Crystal
Gamma-ray detection
Medical imaging research
High-energy physics detector development
Low-background detector studies
Radiation monitoring
Custom scintillator assemblies
Ordering
Request a YSO(Ce) Crystal Quotation
Use the YSO(Ce) crystal inquiry form or email sales@atrscintillator.com. Include the following details:
- Application and radiation energy range, including any background-sensitive measurement.
- Crystal geometry, dimensions, tolerances, quantity and drawing.
- Surface finish, light-collection face and reflector or packaging requests.
- Photosensor or optical readout, coupling arrangement and mounting requirements.
- Signal-response or background acceptance criteria with test conditions, plus requested inspection records and delivery schedule.
The material, processing scope and requested configuration are reviewed before quotation.
Frequently Asked Questions
What information is needed for a YSO(Ce) Scintillation Crystal quotation?
Can ATR Crystal customize YSO(Ce) Scintillation Crystal?
What applications is YSO(Ce) Scintillation Crystal used for?
Does lutetium-free YSO(Ce) mean zero detector background?
Define the energy interval, crystal dimensions, acquisition time and background limit, and identify the surrounding components included in the measurement. State whether the result is required for the crystal or an assembled readout. Avoid using the absence of lutetium as a substitute for an agreed background measurement under the intended conditions.
Can samples and production quantities both be supplied?
Can an existing LYSO drawing be used unchanged to order YSO(Ce)?
It can serve as a starting point for geometry, but update the material designation and review the scintillation, optical-readout and acceptance requirements. Identify which dimensions must remain fixed and which performance targets need reassessment. The similar material abbreviations should not be taken to mean that a YSO component will reproduce the response of a LYSO component.
